Description
Portable ConferenceCam with Bluetooth speakerphone for the huddle room, home office, and on the go
- Superior video and audio with a compact, 76 mm footprint
- Works with your meeting and video conferencing applications
- Plug-free mobility with rechargeable battery
FLEXIBLE VIDEO FOR THE ANYWHERE WORKPLACE
Simplify video conferencing so anyone can set it up and run a meeting anywhere. Make it affordable so you can outfit every conference room with video. Designed for huddle rooms and home offices, Logitech Connect is also compact and mobile so you can take it throughout the workplace and around the world. Connect is always ready for your next video conference call.
PERFECT FOR SMALL SPACES
Logitech Connect goes beyond its award winning design — video conferencing so simple to use that anyone can set it up and so affordable you can enable every meeting room with video. Designed for tabletop placement and small spaces, this video conference solution offers a generous 90° diagonal field-of-view with pan and tilt, 4x zoom, and razor-sharp optics making it easy to see everyone in the room.
COMPATIBLE WITH MOST VC APPS
Connect offers a plug-and-play USB connection to Windows and Mac®computers and Chromebooks™, and is certified for Skype for Business, Cisco Jabber™ compatible, and offers enhanced integration with BlueJeans, Broadsoft, LifeSize Cloud, Vidyo, and Zoom.
PREMIUM CAMERA LENS
Connect features a premium glass lens for maximum clarity. Enjoy bright, clear video with accurate color rendition and sharpness, even when zoomed in. Easily protect the lens from dust and scratches by docking the magnetic remote control.
EASY AUDIO CONFERENCING
Dialing into an audio conference? Already connected on your smartphone? Simply pair Connect via either Bluetooth® or NFC to enjoy outstanding audio clarity, volume, and dynamic range. Connect features two omnidirectional microphones and 360° wideband audio so everyone can hear and be heard.
PORTABLE POWER
Designed for convenient portability, Connect boasts an internal, rechargeable battery that can run video calls for up to 3 hours, and audio calls for up to 15 hours. Or, power Connect with the included AC power supply: swappable regional plugs (included) make it easy to to power and charge around the world.
USB PLUG-AND-PLAY CONNECTIVITY
With no special software, training, or maintenance required, launching an enterprise-quality videoconference has never been easier. Simply plug Connect into your PC, Mac, or Chromebook: it works as both a webcam and an audio device with your video conferencing software.
SAFE AND SECURE
Connect’s remote control docks over the lens, providing an extra level of privacy. And when you want Connect to stay put, the Kensington security slot offers simple protection from theft.
·DIMENSIONS
Main Unit:
- Height x Width x Depth:
- 304.2 mm x 75 mm x 75 mm
- Weight: 766 g
Remote Control:
- Height x Width x Depth:
- 128 mm x 41 mm x 9 mm
- Weight: 32 g
SYSTEM REQUIREMENTS
- Windows® 7, 8.1 or 10
macOS X 10.10 or higher
Chrome OS™
·TECHNICAL SPECIFICATIONS
CAMERA
- Full HD 1080p video calling (up to 1920 x 1080 pixels); 720p HD video calling (up to 1280 x 720 pixels) with supported clients
H.264 UVC 1.5 with Scalable Video Coding (SVC)
Supports H.264 SVC 1080p, along with optimizations for best call performance in single or multiparty HD video
Field of View
- Diagonal: 90°
- Horizontal: 82.1°
- Vertical: 52.2°
4X digital zoom
Rightlight™ 2 Technology for clarity in various lighting environments, even low light
Digital pan, tilt and zoom from remote control or optional downloadable app
Mechanical tilt wheel
Camera LED for active streaming indication
SPEAKERPHONE
- Integrated full duplex speakerphone with echo and noise cancellation
360° wideband audio
Bluetooth® and NFC enabled
LEDs for speakerphone streaming, mute, hold, and Bluetooth pairing
Controls for call answer/end, volume and mute
Microphones (Tx)
- Two omni-directional microphones supporting 3.6 m diameter range
Frequency response: 100Hz – 16KHz
Sensitivity: -34dB +/-3dB
Distortion: <1% @ 1KHz at 65dB
Speakers (Rx)
- Frequency response: 140Hz – 16KHz
Sensitivity: 89dBSPL +/-3dB at 1W/0.5M
Max output: 91.5dBSPL at 0.5M
Distortion: <5% from 200Hz
REMOTE CONTROL
- Docks on device and functions as a lens cover
IR 10-ft (3 m) range
CR2032 battery (included)
CABLES / POWER
- AC Power adapter with regional plugs
USB cable (6ft/1.8 m)
Integrated rechargeable battery
MOUNT
- Designed for tabletop use
Kensington security slot
COMPATIBILITY AND CERTIFICATIONS
- Plug-and-play USB connectivity
Certified for Skype for Business and ready for Teams
Zoom Certified
Fuze Certified
Compatible with Google Meet
Cisco Jabber® and WebEx compatible
Compatible with BlueJeans, BroadSoft, GoToMeeting, Vidyo, and other video conferencing, recording, and broadcasting applications that support USB cameras
·PACKAGE CONTENTS
- Logitech Connect device
Remote control
1.8 meter USB cable
Power adapter with regional plugs
Documentation
